APC BX2200MI-MS Back-UPS 2200VA, 230V, AVR, 4 universal outlets


APC BX2200MI-MS Back-UPS is from the Back-UPS BX series which has comprehensive VA range with premium features further enables single UPS capabilities.

APC™ Back-UPS™ BX series is a cost effective power protection solution for home and home office environments.

SKU: BX2200MI-MS Categories: , Tags: , Brand:

APC BX2200MI-MS Back-UPS 2200VA, 230V, AVR, 4 universal outlets
Model: BX2200MI-MS



Run time for load 1200 W
2min 15s
Max. Capacity Used
100 %
Main Input Voltage 230 V
rated power in W 1200 W
Rated power in VA 2200 VA
output connection type 4 universal
Cable length 1.22 m
Number of cables 1
Battery type Lead-acid battery
Batteries & Runtime
Number of battery filled slots 0
Number of battery free slots 0
Battery recharge time 8 h
Battery voltage 24 V
Battery power in VAH 190 VAh runtime
216 VAh capacity
Battery life 3…5 year(s)
Replacement battery APCRBC177
Battery graph comments Curve fit to measured runtime data. All measurements taken with new, fully charged batteries, at typical environmental conditions, with no electrical input and balanced resistive load (PF = 1.0) output.
Extended runtime 0
Provided equipment User manual
Max runtime 240 min
Number of power module free slots 0
Number of power module filled slots 0
Redundant No
Colour Black
Height 19 cm
Width 14 cm
Depth 39 cm
Product weight 12.3 kg
Mounting preference No preference
Mounting mode Not rack-mountable
Two post mountable 0
USB compatible No
Network frequency 50/60 Hz +/- 5 Hz auto-sensing
Input voltage limits 140…300 V
Input Power Factor at Full Load 0.54
Maximum configurable power in W 1200 W
Output frequency 50/60 Hz +/- 1 Hz sync to mains
UPS type Line interactive
Wave type Stepped approximation to a sinewave
Full load runtime 00:01:00 1200 W
Half load runtime 00:08:30 600 W
Maximum configurable power in VA 2200 VA
Transfer time 6 ms typical : 10 ms maximum
Product certifications CE
Standards EN/IEC 62040-1:2019/A11:2021
EN/IEC 62040-2:2006/AC:2006
EN/IEC 62040-2:2018
Equipment protection policy Lifetime : 50000 euros
Ambient air temperature for operation 0…40 °C
Relative humidity 0…95 % non-condensing
Operating altitude 0…3000 m
Ambient air temperature for storage -15…40 °C
Storage Relative Humidity 0…95 % non-condensing
Storage altitude 0…3000 m
Acoustic level 40 dBA
IP degree of protection IP20
Communications & Management
Control panel LED Status display with on line : on battery
Surge Protection and Filtering
Surge energy rate 273 J
Packing Units
Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 29.7 cm
Package 1 Width 49.5 cm
Package 1 Length 23.5 cm
Package 1 Weight 13.3 kg
SCC14 10731304410734
Contractual warranty
Warranty 2 years repair or replace
