APC BX625CI-MS Back-UPS 625VA 230V AVR Floor Universal Sockets
Model: BX625CI-MS
APC Back-UPS,325 Watts /625 VA,Input 230V /Output 230V, Extended runtime model
Output
Output Power Capacity
325 Watts / 625 VA
Max Configurable Power
325 Watts / 625 VA
Nominal Output Voltage
230V
Efficiency at Full Load
65.3%
Topology
Line Interactive
Waveform Type
Square wave
Output Connections
(3) Universal Receptacle (Battery Backup)
Efficiency at Half Load
75.8%
Input
Nominal Input Voltage
230V
Input Frequency
45 – 65 Hz
Input Connections
IEC-320 C14
Cord Length
1.22 meters
Input voltage range for main operations
151 – 299V
Maximum Input Current
3A
Input Breaker Capacity
7 A
Type of Input Protection Required
3-pole breaker
Batteries & Runtime
Battery Type
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Included Battery Modules
1
Typical recharge time
6 hour(s)
Replacement Battery
(Service center technician only)
(Service center technician only)
APCRBC110
Surge Protection and Filtering
Surge energy rating
273 Joules
Physical
Maximum Height
278.00 mm
Maximum Width
160.00 mm
Maximum Depth
88.00 mm
Net Weight
5.00 KG
Shipping Weight
5.20 KG
Shipping Height
399.00 mm
Shipping Width
215.00 mm
Shipping Depth
128.00 mm
Master Carton Units
1.00
Color
Black
SCC Codes
1073130430817 8
Units per Pallet
100.00
Environmental
Operating Environment
0 – 40 °C
Operating Relative Humidity
0 – 95%
Storage Temperature
-15 – 40 °C
Storage Relative Humidity
0 – 95%
Audible noise at 1 meter from surface of unit
45.00 dBA
Standard Warranty
2 years repair or replace
